DJI Sharper Vision

Aircraft

Weight (Battery & Propellers Included)1368 g
Diagonal Size (Propellers Excluded)350 mm
Max Ascent Speed S-mode: 6 m/s
P-mode:5 m/s
Max Descent Speed S-mode:4 m/s
P-mode:3 m/s
Max SpeedS-mode: 45 mph (72 kph)
A-mode: 36 mph (58 kph)
P-mode: 31 mph (50 kph)
Max Tilt AngleS-mode:42°
A-mode:35°
P-mode:25°
Max Angular SpeedS-mode: 250°/s
A-mode: 150°/s
Max Service Ceiling Above Sea Level19685 feet (6000 m)
Max Wind Speed Resistance10 m/s
Max Flight TimeApprox. 30 minutes
Operating Temperature Range32° to 104°F (0° to 40°C)
Satellite Positioning SystemsGPS/GLONASS
Hover Accuracy RangeVertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS Positioning)
Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GPS Positioning)

Vision System

Vision SystemForward Vision System
Downward Vision System
Velocity Range≤31 mph (50 kph) at 6.6 ft (2 m) above ground
Altitude Range0 - 33 feet (0 - 10 m)
Operating Range0 - 33 feet (0 - 10 m)
Obstacle Sensory Range2 - 98 feet (0.7 - 30 m)
FOVForward: 60°(Horizontal), ±27°(Vertical)
Downward: 70°(Front and Rear), 50°(Left and Right)
Measuring FrequencyForward: 10 Hz
Downward: 20 Hz
Operating EnvironmentSurface with clear pattern and adequate lighting (lux>15)

Remote Controller

Operating Frequency2.400 - 2.483 GHz
Max Transmission Distance2.400 - 2.483 GHz (Unobstructed, free of interference)
FCC: 4.3 mi (7 km)
CE: 2.2 mi (3.5 km)
SRRC: 2.5 mi (4 km)
Operating Temperature Range32° to 104°F (0° to 40°C)
Battery6000 mAh LiPo 2S
Transmitter Power (EIRP)2.400 - 2.483 GHz
FCC: 26 dBm
CE: 17 dBm
SRRC: 20 dBm
MIC: 17 dBm
Operating Current/Voltage1.2 A@7.4 V
Video Output PortGL300E: HDMI
GL300C: USB
Mobile Device HolderGL300E: Built-in display device (5.5 inch screen, 1920×1080, 1000 cd/m2, Android system, 4 GB RAM＋16 GB ROM)
GL300C: Tablets and smart phones

Intelligent Flight Battery

Capacity5870 mAh
Voltage15.2 V
Battery TypeLiPo 4S
Energy89.2 Wh
Net Weight468 g
Charging Temperature Range41° to 104°F (5° to 40°C)
Max Charging Power160 W
hdmi

Gimbal

Stabilization3-axis (pitch, roll, yaw)
Controllable RangePitch: -90° to +30°
Max Controllable Angular SpeedPitch: 90°/s
Angular Vibration Range±0.02°

Camera

Sensor1’’ CMOS
Effective pixels: 20M
LensFOV 84° 8.8 mm/24 mm (35 mm format equivalent) f/2.8 - f/11 auto focus at 1 m - ∞
ISO RangeVideo:
100 - 3200 (Auto)
100 - 6400 (Manual)
Photo:
100 - 3200 (Auto)
100- 12800 (Manual)
Mechanical Shutter Speed8 - 1/2000 s
Electronic Shutter Speed8 - 1/8000 s
Image Size3:2 Aspect Ratio: 5472 × 3648
4:3 Aspect Ratio: 4864 × 3648
16:9 Aspect Ratio: 5472 × 3078
PIV Image Size4096×2160(4096×2160 24/25/30/48/50p)
3840×2160(3840×2160 24/25/30/48/50/60p)
2720×1530(2720×1530 24/25/30/48/50/60p)
1920×1080(1920×1080 24/25/30/48/50/60/120p)
1280×720(1280×720 24/25/30/48/50/60/120p)
Still Photography ModesSingle Shot
Burst Shooting: 3/5/7/10/14 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Interval: 2/3/5/7/10/15/20/30/60 s
Video Recording ModesH.265
C4K:4096×2160 24/25/30p @100Mbps
4K:3840×2160 24/25/30p @100Mbps
2.7K:2720×1530 24/25/30p @65Mbps
2.7K:2720×1530 48/50/60p @80Mbps
FHD:1920×1080 24/25/30p @50Mbps
FHD:1920×1080 48/50/60p @65Mbps
FHD:1920×1080 120p @100Mbps
HD:1280×720 24/25/30p @25Mbps
HD:1280×720 48/50/60p @35Mbps
HD:1280×720 120p @60Mbps

H.264
C4K:4096×2160 24/25/30/48/50/60p @100Mbps
4K:3840×2160 24/25/30/48/50/60p @100Mbps
2.7K:2720×1530 24/25/30p @80Mbps
2.7K:2720×1530 48/50/60p @100Mbps
FHD:1920×1080 24/25/30p @60Mbps
FHD:1920×1080 48/50/60 @80Mbps
FHD:1920×1080 120p @100Mbps
HD:1280×720 24/25/30p @30Mbps
HD:1280×720 48/50/60p @45Mbps
HD:1280×720 120p @80Mbps
Max Video Bitrate100 Mbps
Supported File SystemsFAT32 (≤32 GB); exFAT (>32 GB)
PhotoJPEG, DNG (RAW), JPEG + DNG
VideoMP4/MOV (AVC/H.264; HEVC/H.265)
Supported SD CardsMicro SD
Max Capacity: 128GB
Write speed ≥15MB/s, Class 10 or UHS-1 rating required
Operating Temperature Range32° to 104°F (0° to 40°C)

Charger

Voltage17.5V
Rated Power100 W

App / Live View

Mobile AppDJI GO 4
Live View Working Frequency2.4 GHz ISM
Live View Quality720P @ 30fps
LatencyPhantom 4 Advanced: 220 ms (depending on conditions and mobile device)
Phantom 4 Advanced +：160 - 180 ms

DOCUMENTS & MANUALS

  • Phantom 4 Advanced/Advanced+ Release Notes
    2017-06-08
    zip
    pdf
  • Phantom 4 Advanced/Advanced+ User Manual v1.0
    2017-10-10
    zip
    pdf
  • Phantom 4 Advanced/Advanced+ User Manual (PTBR) v1.0
    2017-07-22
    zip
    pdf
  • Phantom 4 Advanced Quick Start Guide v1.0
    2017-04-13
    zip
    pdf
  • Phantom 4 Advanced+ Quick Start Guide v1.0
    2017-04-13
    zip
    pdf
  • Phantom 4 Series Disclaimer and Safety Guidelines v1.2
    2017-10-12
    zip
    pdf
  • Phantom 4 Advanced In the Box
    2017-04-13
    zip
    pdf
  • Phantom 4 Advanced+ In the Box
    2017-04-13
    zip
    pdf
  • Phantom 4 Series Intelligent Flight Battery Safety Guidelines
    2017-04-13
    zip
    pdf

SOFTWARE

  • DJI Assistant 2 For Phantom
    url

APP / LIVE VIEW

    iOS V 4.3.37
    Requires iOS 10.0.0 or later (Mavic 2 Pro/Zoom requires iOS 10.0.2 or later).
    Compatible with iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone SE, iPad Pro, iPad, iPad Air 2, iPad mini 4.
    Optimized for iPhone X.

    Android V4.3.40
    Requires Android 5.0 or later.
    Compatible with Samsung S9+, Samsung S9, Samsung S8+, Samsung S7, Samsung S7 Edge, Samsung S6, Samsung S6 Edge, Samsung Note 8, Huawei P20 Pro, Huawei P20, Huawei P10 Plus, Huawei P10, Huawei Mate 10 Pro, Huawei Mate 10, Huawei Mate 9 Pro, Huawei Mate 9, Huawei Mate 8, Honor 10, Honor 9, Vivo X20, Vivo X9, OPPO Find X, OPPO R15, OPPO R11, Mi Mix 2S, Mi Mix 2, Mi 8, Mi 6, Redmi Note 5, Google Pixel 2XL, OnePlus 6, OnePlus 5T.

    *Support for additional devices available as testing and development continues.

FIRMWARE

  • Phantom 4 Advanced+ Remote Controller Firmware v01.04.03.00
    2018-04-13
    zip
  • How to Update Phantom 4 Advanced+ Remote Controller Firmware
    2017-05-05
    pdf
PRODUCT
The Phantom 4 Advanced's uprated camera shoots 4K/60 fps video at a bitrate of 100 Mbps and stills at up to 20 megapixels. It can be used with an optional integrated monitor for even more reliable transmission. Operators are empowered with a new suite of Intelligent Flight Modes.The maximum flight speed of the Phantom 4 Advanced is slightly higher than the Phantom 4 when flying in P-mode. The maximum flight time is extended to 30 minutes, the transmission range is extended to 7 km, and the obstacle sensing range is increased from 15 m to 30 m.
The Phantom 4 Advanced inherits most of the functions of the Phantom 4 Pro. However, in order to increase affordability, unlike the Phantom 4 Pro the Phantom 4 Advanced does not have rear vision sensors and two infrared sensors in its FlightAutonomy system. Also, its remote controller does not support the 5.8 GHz frequency band and Tapfly Backward has been removed.
Propellers, Intelligent Flight Batteries, chargers, power cables and micro USB cables can be used with both the Phantom 4 and Phantom 4 Advanced.
We're not planning to release additional color options for the P4A. Currently, only the P4P and P4P+ will have Obsidian color versions.
CAMERA
The Phantom 4 Advanced camera is able to record UHD 4K (4096X2160) at 60 fps, at a maximum bitrate of 100 Mbps using the H.265 codec. It also allows you to capture still images while filming. The Phantom 4 Advanced camera sensor is also larger than the Phantom 4 camera sensor, ensuring clearer images.
The mechanical shutter eliminates rolling shutter distortion, which can occur when capturing images of fast moving subjects with an electric shutter.
Yes, it does. Tap a point on the display to focus at that point after switching from metering to focus mode. Autofocus can also be triggered by half-pressing the shutter button but only with the Plus RC, before fully pressing the shutter to capture an image. Focus can be set between 1 m and infinity.
The Phantom 4 Advanced's camera has a wide-angle lens specially designed for aerial photography, with an aperture range of F2.8 to F11 and a 24 mm equivalent focal length. It’s also equipped with a mechanical shutter and auto focus support.
OBSTACLE SENSING SYSTEM
The obstacle sensing range of the Phantom 4 Advanced front vision sensor has been increased to 30 m.
You can do a quick vision system calibration via the DJI GO 4 app, or do an advanced calibration by launching the DJI Assistant 2 in your computer.
REMOTE CONTROLLER
Compared to the Phantom 4 Pro, the Phantom 4 Advanced remote controller doesn't support the 5.8 GHz frequency band. The Phantom 4 Advanced+ remote controller has a built-in screen.
The Phantom 4 Advanced controller is compatible with other Phantom 4 series aircrafts except the Phantom 4 Pro V2.0/V2.0 Plus.
INTELLIGENT FUNCTIONS
The new Phantom 4 Advanced Intelligent Flight Modes include Draw, Gesture, an upgraded TapFly, Tripod, Terrain Follow and an upgraded ActiveTrack.
PROPULSION SYSTEM
The maximum flight speed of the Phantom 4 Advanced in P-mode is 14 m/s.
