Weight (without payload)55.2kg (with Lifting system)
60.2kg (with Winch system)
Excludes the weight of the battery, dual battery compartment and accessories, cable, and hook.
Max Takeoff Weight170kg
The 170kg maximum takeoff weight is the performance specification of the drone. Please follow local laws and regulations in actual use. In the following countries and regions the maximum takeoff weight is restricted to 150kg: Brazil, Japan, Australia, Turkey, Saudi Arabia.
Max Diagonal Wheelbase(motor to motor)2330mm
Diagonal length (tip to tip)3904mm
Dimensions (arms & propellers unfolded)3220mm × 3224mm × 975mm
Overall dimensions arms folded, propellers unfolded)1820mm × 1840mm × 975mm
Overall dimensions (arms & propellers unfolded)1105 mm × 1265 mm × 975 mm
Folding MethodTowards body
Loadable Battery QuantitySupports dual battery and single battery configurations
Single battery Mode is for emergency use.
Max Flight DistanceUnder 149.9kg takeoff weight: dual battery 12 km, single battery 6 km
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, flying at a constant optimal speed to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Max Hovering EnduranceUnder 149.9kg takeoff weight: dual battery 12 minutes, single battery 6 minutes
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, hovering to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Max Flight TimeUnder 149.9kg takeoff weight: dual battery 14 minutes , single battery 7 minutes.
This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, flying at a constant optimal speed to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.
Operating Temperature-20℃ to 40℃
Measured with estimated solar radiation of 960 W/m 2. Long-term exposure to high temperatures may shorten the service life of certain components.
Ingress Protection RatingIP55
The protection rating is not permanent and may decline due to aging and wear caused by long-term use. The protection rating does not apply to the propulsion system. After a flight in rain, it is recommended to keep it idling on the ground for 1 minute to prevent corrosion or rust to afflict the propulsion system (precipitation of more than 24.9 mm within 24 hours).
Hovering Accuracy (with strong GNSS signal)RTK positioning enabled:
± 10 cm (horizontal), ± 10 cm (vertical)
RTK positioning disabled:
± 60 cm (horizontal), ± 30 cm (vertical)
RTK/GNSS Operating Frequency GPS + Galileo + BeiDou + GLONASS
Max Ascent Speed5 m/s
Measured in dual battery mode at sea level in a 25℃ windless experimental condition.
Max Descent Speed5 m/s
Measured in dual battery mode at sea level in a 25℃ windless experimental condition.
Max Horizontal Speed20 m/s
Measured in dual battery Mode at sea level in a 25℃ windless experimental condition.
Max Flight Altitude(above the sea level)6,000 m
Drone payload capacity decreases with increasing Taking off Height. 6,000 m above sea level is the maximum safe Height for the drone with two batteries and no payload (Taking off at 4,500 m above sea level).
Maximum Flight Altitude (relative to takeoff point)1,500 m
flight altitude is constrained by Taking off altitude. The maximum flight altitude for DJI FC100 is 6,000 m.
Max Wind Speed Resistance12 m/s
The maximum wind resistance during the Taking off and Land Stage is 12 m/s.
