Support for DJI Dock 4

Battery Swapping + Wireless Charging

< 25 s

Time elapsed from when the Dock Cover is fully closed to the completion of the battery swap. Measured in a controlled test environment and is for reference only.

< 45 s

Time elapsed from when the aircraft lands from the previous flight to when it completes the battery swap and takes off again. Measured in a controlled test environment and is for reference only.

3

The dock has four battery compartments, each designed to hold one battery. To ensure proper operation of the battery-swapping mechanism, no more than three of the four compartments may contain a battery at any given time.

2

Per-channel output voltage: 15-25.8 V DC

Per-battery charging time: 27 minutes

Time required to charge the battery in the battery compartment from 15% to 95% level in a 25° C (77° F) environment.

High-speed Wi-Fi connection:
2.4000-2.4835 GHz: < 23 dBm (IC), < 20 dBm (CE/SRRC/MIC)
5.7250-5.8500 GHz: < 23 dBm (IC/SRRC), < 14 dBm (CE)

DJI O4 Enterprise Enhanced Video Transmission System:
Supported via DJI O4 Ground Station

The supported operating frequency bands and their corresponding availability vary by country/region. For details, please refer to local laws and regulations.

High-speed Wi-Fi connection: Single antenna
DJI O4 Enterprise Enhanced Video Transmission System: Integrated into the O4 Ground Station

Compressor-based air conditioning

48 V DC

Backup power is supplied by the aircraft battery housed in the dock battery compartment.

12138 mAh

21.42 V

LiNiMnCoO2

Operating time per battery: approx. 4.5 hours
Supports sequential power supply across three batteries

Measured in a 25° C (77° F) environment with the backup battery discharged from 90% to 10%. After a power outage, the dock does not support functions like aircraft charging, air conditioning operation, and wind speed gauge heating. Please restore power promptly.

Supported (requires connection to DJI O4 Ground Station)

Requires use with DJI Cellular Dongle 2 (installed on DJI O4 Ground Station).

Supported

Supported

Supported

Supported

Supported

1920×1080

151°

Auxiliary White Light

1920×1080

151°

Auxiliary White Light

20 kA (rated value), meets EN 61643-11 Type 2 and IEC 61643-1 Class Ⅱ protection level requirements

10 kA (Itotal), meets EN/IEC 61643-21 Category C protection level requirements

DJI Enterprise App (for on-site setup, testing, remote operations, live viewing, and one-tap drone dispatch)

FlightHub 2
FlightHub 2 On-Premises Version
FlightHub 2 FlightHub Sync
DJI Cloud API

170×170×352 mm

2.68 kg

Direct connection to DJI Dock power supply: -40° to 55° C (-40° to 131° F)

The 55° C (131° F) upper limit accounts for solar radiation. At -40° C (-40° F), the device requires a windless environment; auto-restart after shutdown is not supported in windy conditions. After storage or operation in extreme temperatures, allow the internal backup battery to return to between 0° and 45° C (32° and 113° F) before charging.

When connected to the DJI Dock 4 PoE port, the device automatically wakes up when plugged in or when power is restored.

Supported

IP67

Please follow the requirements stated in the IP67 protection rating instructions. Measured in a controlled environment. The IP rating is not permanently effective and may decrease due to product wear and tear.
When the O4 Ground Station is installed close to the dock, use the Ethernet cable included in the package. When it is installed farther away, use the included waterproof Ethernet port connector. The cable must be Cat 6 or above outdoor-rated, waterproof twisted-pair cable with an outer diameter of 5.5 to 6.5 mm. Install the corrugated tubing and corrugated tubing plug, crimp the RJ45 connector, and tighten the connector nut.
Ensure all rubber port covers and the DJI Cellular Dongle 2 heat sink are properly installed. Unused WAN/LAN port screws must be fully tightened.

GPS: L1C/A, L2C, L5
BDS: B1I, B2I, B3I, B1C, B2a, B2b
GALILEO: E1, E5a, E5b, E6
GLONASS: L1, L2
QZSS: L1C/A, L2C, L5
L-Band

Horizontal: 1.0 cm (RMS) + 1 ppm
Vertical: 3.0 cm (RMS) + 1 ppm

RTK calibration is required. Measurement accuracy depends on various factors. This value is obtained under normal conditions with an unobstructed view, good satellite distribution, low ionospheric activity, and no electromagnetic interference or multipath effects.

DJI O4 Enterprise Enhanced Video Transmission System

902 MHz to 928 MHz: < 30 dBm (IC), < 16 dBm (MIC)
2.400 GHz to 2.4835 GHz: < 33 dBm (IC), < 20 dBm (CE/SRRC/MIC)
5.150 GHz to 5.250 GHz: < 21 dBm (IC)
5.170 GHz to 5.250 GHz: < 23 dBm (CE)
5.725 GHz to 5.850 GHz: < 33 dBm (IC), < 14 dBm (CE), < 30 dBm (SRRC)

Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.

OcuSync 4 Pro external directional antenna × 4
OcuSync 4 Pro internal directional antenna × 8

2.4G/5.2G/5.8G: 2T4R
sub2G: 2T2R

4G Antenna × 2

Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.

Ethernet Access: Adaptive Ethernet port; Gigabit network is recommended, with both uplink and downlink bandwidth > 20 Mbps, preferably > 40 Mbps (when no other peripherals are connected), and network latency ≤ 100 ms for a better user experience*
4G Access: Requires the DJI Cellular Dongle 2**

* If these requirements are not met, the device may go offline or experience video stuttering.
** Sold separately. This service is not available in some countries and regions. Please consult your local dealer for details.

Ethernet Port (PoE)
WAN: PoE-in
LAN: PoE-in

Cat 6 or above outdoor-rated, waterproof twisted-pair cable; max length 80 m; outer diameter 5.5 to 6.5 mm

To reduce the risk of waterproofing failure and other reliability issues, use the Ethernet cable included with the DJI Dock for cable runs of less than 5 m from the Dock.

With DJI Dock 4:
Max Power Consumption (Including Heating): 65 W
Typical Power Consumption (Without Heating): 17.1 W
Low-Power Mode: 7 W**

* Measured in a controlled test environment and should be used for reference only. Actual power draw may be higher when accounting for losses in the power supply.
** Low-power mode is not recommended for use at temperatures of -40° to -20° C (-40° to -4° F).

Li-ion
Capacity: 3250 mAh
Energy: 23.4 Wh

Battery preservation mode is enabled by default when powered via PoE. In the event of a sudden power loss, estimated runtime is 45 minutes.

Battery preservation mode: when powered via PoE, the system keeps battery voltage between 7.0 V and 7.4 V. If the battery voltage at insertion exceeds 7.5 V, the system will discharge it to the safe threshold before entering preservation mode; the battery will not charge to full capacity.
Battery discharge performance may decrease in low temperatures, reducing actual operating time.

Supports 9V or 12V PD charging. DJI 65W Portable Charger is recommended before deployment. When fully charged, estimated runtime is approx. 2 hours.
Charge time (65W PD): approx. 2.5 hours

Charging with a 5V charger is only supported when the device is powered off.
Charging is only supported when the battery cell temperature is between 0° and 55° C (32° and 131° F).

WAN/LAN Ports: Ethernet interface supports up to 10 kA (total discharge current) surge protection, meeting EN/IEC 61643-21 Category C.

Surge protection capability depends on the capacity and reliability of grounding. To minimize the risk of surges, please make sure that grounding is done properly during installation.

DJI Enterprise App (for on-site setup, testing, remote operations, live viewing, and one-tap drone dispatch)

FlightHub 2
FlightHub 2 On-Premises Version
FlightHub 2 FlightHub Sync
Third-party cloud platform developed based on DJI Cloud API

Supports cameras using ONVIF and GB/T 28181 protocols
Supports up to 4 simultaneous 1080p H.264 video streams

The camera and the WAN port of the DJI O4 Ground Station must be connected to the same upstream switch. For details, see the DJI O4 Ground Station - IP Camera Configuration Guide.

ESDK 2.0

DJI Matrice 5TD

2600 g

This value includes the weight of the battery, propellers, and a microSD card, but does not include third-party payloads. The actual weight may vary due to differences in batch materials and external factors.

3050 g

393×477×230 mm (L×W×H, without propellers)

Diagonal Wheelbase: 549 mm

6 m/s

6 m/s

21 m/s

Currently, only FlyTo Tasks (Fly to a Target Point) support flight speeds of up to 21 m/s. In other modes, the maximum flight speed is 15 m/s.

12 m/s

6500 m

Aircraft without payload.

4500 m

59 minutes

Measured under the following conditions: in a windless laboratory environment at 20 meters above sea level, with the aircraft flying forward without payload at a constant speed of 15 m/s from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

55 minutes

Measured with the aircraft hovering in a windless environment at 20 meters above sea level and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

10 km

Measured in an environment of approximately 25° C (77° F) with a safe battery level of 15%, windless environment, round-trip flight speed of approximately 15 m/s, and hovering operation without payload of 25 minutes. Results may vary depending on the environment, actual use, and firmware version.

53 km

Measured with the aircraft flying at a constant speed of 15 m/s in a windless environment at 20 meters above sea level and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

25°

Currently supported in Normal Mode only.

75°/s

Currently supported in Normal Mode only.

GPS + Galileo + BeiDou + QZSS + GLONASS

Vertical:
±0.1 m (with vision positioning)
±0.04 m (with RTK positioning)

Horizontal:
±0.3 m (with vision positioning)
±0.02 m (with RTK positioning)

-40° to 50° C (-40° to 122° F)

IP55

3409.6

1564F foldable low-noise anti-ice propellers

Integrated on the aircraft

Integrated on the aircraft

A customizable multicolor warning light, integrated into the bottom of the aircraft

Two on the sides and one on the top

Requires the Matrice 5TD Accessory Mount.

Omnidirectional binocular color vision system; horizontal rotating LiDAR; downward 3D infrared ranging sensor; and forward, upward, and downward mmWave radars

Measurement Range: 0.5 m to 25 m
Detection Range: 0.5 m to 200 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 95°, Vertical 90°

Measurement Range: 0.5 m to 25 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 95°, Vertical 90°

Measurement Range: 0.5 m to 25 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 90°

Measurement Range: 0.5 m to 20 m
Effective Sensing Speed: Flight Speed ≤ 10 m/s
FOV: Front and Back 95°, Left and Right 90°

Measurement Range: 0.5 m to 20 m
Effective Sensing Speed: Flight Speed ≤ 8 m/s
FOV: Front and Back 90°, Left and Right 95°

Forward, Backward, Left, Right, and Upward: Surfaces with discernible patterns and adequate lighting (lux > 0.1)
Downward: Diffuse reflective surface with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 0.1)

Standard Measurement Range: 110 m @ 100,000 lux with 10% reflectivity target

Measurement Range for Power Line: 32 m @ 30° @ 35,000 lux for 21.6 mm steel-core aluminum stranded wire with a relative body tilt angle of 30° to the left and right
19 m @ 30° @ 35,000 lux for 11 mm black rubber cable (with surface soiling) with a relative body tilt angle of 30° to the left and right

Field of View (FOV): 360° (horizontal), 59° (vertical)

Point-Frequency: 250,000-460,000 points/second

Laser Wavelength: 940 nm

Safety Classification: Class 1 (IEC 60825-1:2014)

Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Front and Rear 60°, Left and Right 60°

FOV: Vertical 90°, Horizontal 90°
Front Millimeter-Wave Radar: 40 m measurement range for a 12 mm black rubber cable directly ahead
Upper and Lower Millimeter-Wave Radars: 20 m measurement range for a 12 mm black rubber cable directly ahead

The mmWave radar function may be unavailable or restricted in some countries or regions. Refer to local laws and regulations for more information.

DJI O4 Enterprise Enhanced Video Transmission System

1080p/30fps (with DJI Dock 4)

DJI O4 Enterprise Enhanced Video Transmission System:
902-928 MHz: < 30 dBm (IC), < 16 dBm (MIC)
1.430-1.444 GHz: < 35 dBm (SRRC)
2.400-2.4835 GHz: < 33 dBm (IC), < 20 dBm (CE/SRRC/MIC)
5.150-5.250 GHz: < 21 dBm (IC)
5.170-5.250 GHz: < 23 dBm (CE)
5.725-5.850 GHz: < 33 dBm (IC), < 14 dBm (CE), < 30 dBm (SRRC)

High-speed Wi-Fi connection (802.11a/b/g/n/ac/ax):
2.4000-2.4835 GHz: < 23 dBm (IC), < 20 dBm (CE/SRRC/MIC)
5.7250-5.8500 GHz: < 23 dBm (IC/SRRC), < 14 dBm (CE)

The supported operating frequency bands and their corresponding availability vary by country/region. For details, please refer to local laws and regulations.

IC: 40 km
SRRC: 25 km
CE/MIC: 12 km

Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in DJI FlightHub 2 during your flight.

Strong Interference (downtown areas): 2.5-5 km
Medium Interference (suburban counties): 5-15 km
Low Interference (remote suburbs/coastal areas): 15-32 km

Data is tested under IC standard in unobstructed environments of typical interference. Only to serve as a reference and provides no guarantee as to the actual flight distance.

Low interference with building obstruction: approx. 0-1 km
Low interference with vegetation obstruction: approx. 1-5 km

Data is tested under IC standard in obstructed environments of typical interference. Only to serve as a reference and provides no guarantee as to the actual flight distance.

20MB/s (with DJI O4 Enterprise Enhanced Video Transmission System)
80MB/s (via high-speed Wi-Fi connection)

Measured in a near-field, interference-free lab in countries/regions that support 2.4 GHz/5.8 GHz dual-band. Download speeds may vary; refer to actual experience. The Wi-Fi high-speed channel download starts automatically after the drone lands at the dock and requires the included SD card. 80 MB/s is the maximum transfer rate for large files like video; the transfer rate may decrease when transferring small files such as photos.

The latency from the aircraft to the FlightHub 2 cloud platform is 160 milliseconds.

Data is for reference only. Actual latency depends on network conditions and computer specs.

8 antennas
2.4G/5.2G/5.8G: 2T4R
sub2G: 2T2R

Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.

Built-in dual 4G modules
Data usage: ≤ 2.25 GB/30 minutes (dual-SIM dual-active backup transmission)

4G is not supported in some countries or regions. Please contact your local dealer for details.

U3/Class10/V30 or above is supported. A list of recommended microSD cards can be found below.

Lexar SILVER PLUS 64GB U3 A2 V30 microSDXC
Lexar SILVER PLUS 128GB U3 A2 V30 microSDXC
Lexar SILVER PLUS 256GB U3 A2 V30 microSDXC
Lexar SILVER PLUS 512GB U3 A2 V30 microSDXC

12138 mAh

21.42 V

25.8 V

Li-ion 6S

LiNiMnCoO2

260 Wh

925 g

400

Storage at high temperatures will shorten the battery's lifespan. If the cumulative storage duration at temperatures above 35° C (95° F) does not exceed 100 days within a 12-month period, the battery can support up to 400 cycles.

10° to 55° C (50° to 131° F)

3C

1.8C

Supports low-temperature self-heating charging

3-axis mechanical gimbal (tilt, roll, pan)

Tilt: -140° to +113°
Roll: -52° to +52°
Pan: -75° to +75°

Soft limits: tilt -130° to +90°, roll -47° to +47°, pan -70° to +70°.

Tilt: -90° to +90°
Pan: Not controllable

±0.005°

100°/s

Wide-Angle Camera: 1/0.98-inch CMOS, Effective Pixels: 50 MP
Medium Tele Camera: 1/1.28-inch CMOS, Effective Pixels: 50 MP
Tele Camera: 1/1.5-inch CMOS, Effective Pixels: 50 MP

Wide-Angle Camera
FOV: 85.7°
Format Equivalent: 23.5 mm
Aperture: f/1.8
Focus: 0.6 m to ∞

Medium Tele Camera
FOV: 35°
Format Equivalent: 70 mm
Aperture: f/2.88
Focus: 3 m to ∞

Tele Camera
FOV: 9.7°
Format Equivalent: 252 mm
Aperture: f/2.8
Focus: 5 m to ∞

Wide-angle, medium tele, and tele cameras all support lens defogging.

Normal Mode: ISO 100 to ISO 25600
Night Scene Mode:
Wide-Angle Camera: ISO 100 to ISO 1638400
Medium Tele Camera: ISO 100 to ISO 1638400
Tele Camera: ISO 100 to ISO 1638400

Wide-Angle Camera: 2-1/8000 s
Medium Tele Camera: 2-1/8000 s
Tele Camera: 2-1/8000 s

Wide-Angle Camera: 8192×6144
Medium Tele Camera: 8192×6144
Tele Camera: 8192×6144

0.5 s

Wide-Angle Camera:
Single: 12 MP / 50 MP
Timed: 12 MP / 50 MP
JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Capture: 12 MP
Panorama: Approx. 110 MP (stitched image)

Medium Tele Camera:
Single: 12 MP / 50 MP
Timed: 12 MP / 50 MP
JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Capture: 12 MP

Tele Camera:
Single: 12 MP / 50 MP
Timed: 12 MP / 50 MP
JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Capture: 12 MP

Video Codec: H.265
Encoding Strategy: CBR, VBR
Resolution:
4K: 3840×2160@30fps
FHD: 1920×1080@30fps

H.265: 40 Mbps

exFAT

JPEG

MP4, TS

Tele Camera:
16× (176× hybrid zoom)

FOV: 5.2° to 6.6°

Normal Incidence Range: 3000 m (1 Hz, @25% reflectivity target*, 8000 m visibility)
Oblique Incidence Range: 1200 m (1 Hz, 1:10 Oblique Distance)
Blind Zone: 1 m
Ranging Accuracy: (@ 20%-90% reflectivity, 1-10 Hz)
Systematic Error:
Within 12 m: < 0.1 m
12 m to 100 m: < 0.3 m
100 m to 3000 m: < 1 m
Random Error:
< 0.1 m (1σ)
Safety Classification: Class 1 (IEC 60825-1:2014)

* Performance degradation may occur in rainy or foggy conditions.

Uncooled VOx Microbolometer

DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or a laser beam. Otherwise, the camera sensor may be burned, leading to permanent damage.

1280×1024

8 μm

30 Hz

DFOV: 45°
Format Equivalent: 53 mm
Aperture: f/0.85
Focus: 10 m to ∞

≤ 50 mK@f/1.0, at an ambient temperature of 25° C (77° F)

Spot Measurement, Area Measurement

High Gain Mode: -40° to 150° C (-40° to 302° F)
Low Gain Mode: 0° to 550° C (32° to 1022° F)

Supported

White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fusion/Rainbow 1/Rainbow 2

JPEG (8-bit)
R-JPEG (16-bit)
DLT-664

UHR Infrared Image Mode: 2560×2048@30fps
Normal Mode: 1280×1024@30fps

12 Mbps (H.265, 1280×1024@30fps)
24 Mbps (H.265, 2560×2048@30fps)

MP4

Single
Normal Mode: 1280×1024
UHR Infrared Image Mode: 2560×2048

Timed
Normal Mode: 1280×1024, 0.7/1/2/3/5/7/10/15/20/30/60 s
UHR Infrared Image Mode: 2560×2048,
0.7/1/2/3/5/7/10/15/20/30/60 s

32×

8-14 μm

High Gain: ±2° C or ±2%, whichever is greater
Low Gain: ±5° C or ±3%, whichever is greater

Supported

Supported

115 g (excluding bracket)

91×54×60 mm (L×W×H, excluding bracket)

Spotlight: 40 W
Floodlight: 18 W
Both On: 48 W

Spotlight: 11.2±0.5 lux @ 100 meters
Floodlight: 2.7±0.2 lux @ 100 meters

This data was measured with the aircraft hovering in a laboratory environment at an ambient temperature of 25° C (77° F).

Spotlight: 14.5° (10% center illuminance)
Floodlight: 23° (10% center illuminance)

Spotlight: 500 square meters @ 100 meters (10% center illuminance)
Floodlight: 1,300 square meters @ 100 meters (10% center illuminance)

Always-On Mode: Spotlight, Floodlight, Both On, and Auto (automatically switches lighting modes based on the zoom level)
Strobe Mode: Slow, Fast

When the spotlight is turned on, visual obstacle sensing is disabled and only the mmWave radar and LiDAR remain active, reducing omnidirectional obstacle sensing performance. Fly with caution.

Tilt: -135° to +135°

Tilt: -90° to +90°

120°/s

±0.1°

-40° to 50° C (-40° to 122° F)

IP55

Mounted on the right side of the aircraft using the Matrice 5TD Accessory Mount. Make sure to tighten the mounting screws during installation.

188 g (excluding bracket)

132×47×54 mm (L×W×H, excluding bracket)

30 W

120.5 dB @ 1m

Data measured in a laboratory environment at 25° C (77° F). Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use.

400 m

Data measured in a laboratory environment at 25° C (77° F). Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use.

Real-time broadcasting, record & broadcast, file import (supports playback during transfer), text-to-speech

Chinese, English, Japanese, Korean, French, Spanish, German

Only Chinese and English support both male and female voices; other languages support female voices only.

-40° to 50° C (-40° to 122° F)

IP55

Mounted on the left side of the aircraft using the Matrice 5TD Accessory Mount. Make sure to tighten the mounting screws during installation.

107 g (excluding bracket)

92×70×56 mm (L×W×H, excluding bracket)

3050 g

0-5000 m

< 6 m/s

Measured in a windless environment at 25° C (77° F), at an altitude between 30 m and 500 m, with DJI Matrice 5TD taking off at the max takeoff weight of 3050 g. Data is for reference only. Actual experience may vary depending on the environment, usage, and firmware version.

≥ 35 m

The minimum effective deployment altitude of DJI AP1 Parachute is 35 m (the minimum vertical altitude required for the parachute to stabilize the aircraft's descent below 6 m/s). If deployed below 35 m, the parachute will still eject, but may not fully inflate to adequately slow the descent. Additionally, in some cases, auto-deployment may not trigger, requiring manual operation. Please fly with caution. For detailed features and trigger conditions, visit the official product page.
The 35 m data was measured in a windless environment at 25° C (77° F), at an altitude below 500 m, with DJI Matrice 5TD taking off at the max takeoff weight of 3050 g. Data is for reference only. Actual experience may vary depending on the environment, usage, and firmware version.

600 ms

Measured in a controlled laboratory environment. With DJI Matrice 5TD hovering and propellers spinning, this is the total time interval recorded from the triggering of the Flight Termination System (FTS) signal, through the confirmation of a complete rotor stop, to the triggering of the gas generator's electrical signal. Data is for reference only. Actual experience may vary depending on the environment, usage, and firmware version.

Manual/Automatic

-40° to 50° C (-40° to 122° F)

IP55

Mounted on top of the aircraft using the Matrice 5TD Accessory Mount. Make sure to tighten the mounting screws during installation.

Aircraft beeping and indicator flashing

30 s

Measured at 25° C (77° F) with the parachute in its factory state, or when the parachute is connected to the aircraft for over 10 minutes of flight time each month. Data is for reference only. Actual experience may vary depending on the environment, usage, and firmware version.

Continuously checks the status of the gas generator and communication links, displaying alerts via the DJI FlightHub 2 Health Management System (HMS) interface.

Supported

40 g

117×126×70 mm (L×W×H)

3
