Specs
General
Model
CN Standard: CDT01-CN
US/JP Standard: CDT01-US
EU Standard: CDT01-EU
Net Weight
CN/US/JP Standard: Approx. 245 g
EU Standard: Approx. 250 g
Dimensions
CN/US/JP Standard (with pins folded): 68.3×32.2×64 mm (L×W×H)
EU Standard (excluding pins): 86.5×35.7×64 mm (L×W×H)
Dimensions may vary slightly due to production batches. Please refer to the actual product.
Number of Ports
USB-C × 2
USB-A × 1
Power Density
1.00 W/cm³
AC Plug Type
CN/US/JP Standard: Foldable Plug Design
EU Standard: Fixed Plug Design
Operating Temperature
0° to 25° C (32° to 77° F)
Input Specifications
AC Input
AC 100-240 V, 50/60 Hz, max current: 2 A
Actual AC input data varies by country and region.
Output Specifications
Total Output
140 W
USB-C Output
5 V, 3 A
9 V, 5 A
12 V, 5 A
15 V, 5 A
20 V, 5 A
28 V, 5 A
Max output power: 140 W
USB-A Output
5 V, 3 A
9 V, 3 A
12 V, 2.25 A
11 V, 3 A
Max output power: 33 W
Output Power Allocation
At 140W full load:
Single Port Output:
• USB-C1 (or USB-C2): 140 W Max
• USB-A: 33 W Max
Dual Port Output:
• USB-C1 + USB-C2: 100 W + 35 W / 35 W + 100 W / 65 W + 65 W
• USB-C1 (or USB-C2) + USB-A: 100 W + 33 W
Triple Port Output:
• Smart dynamic power allocation, with a total output not exceeding 140 W
• USB-C1 + USB-C2 + USB-A: 80 W + 35 W + 22 W / 35 W + 80 W + 22 W / 65 W + 50 W + 22 W
If multiple ports are in use and one is connected to a DJI device, the charger supports dynamic power allocation and prioritizes power supply to connected DJI devices. This priority function is only available for select DJI devices and requires a DJI Power 7A USB-C Digital Display Cable connected to the USB-C1 or USB-C2 port. For detailed supported devices, refer to the FAQ page on the official DJI website. Unplug any idle cables when not in use to avoid limiting the max charging power of other ports. The charger features over-temperature protection and will automatically reduce output power if the temperature reaches the safety threshold during full-load operation.
Digital Display Cable
Model
CDX01-GB-1M0
CDX01-GB-1M8
Length
1 m/1.8 m
Connector Dimensions
27×11.5×7.6 mm (L×W×H)
Dimensions may vary slightly due to production batches. Please refer to the actual product.
Display Type
OLED
Connector Type
USB-C to USB-C
Max Current
7 A
Max Output Power
240 W
FAQ
GaN Charger
Does the charger overheat while charging? Is it safe to use?
GaN chargers generate some heat under high-power output, which is normal.
DJI Power 140W GaN Charger uses an optimized heat-dissipation structure and GaN technology, so it generates less heat than conventional chargers. When high temperatures are detected, the charger automatically reduces its output power. Additionally, the charger features a built-in over-temperature protection system, supporting multiple safeguards such as overvoltage, overcurrent, and short-circuit protection.
DJI Power 140W GaN Charger uses an optimized heat-dissipation structure and GaN technology, so it generates less heat than conventional chargers. When high temperatures are detected, the charger automatically reduces its output power. Additionally, the charger features a built-in over-temperature protection system, supporting multiple safeguards such as overvoltage, overcurrent, and short-circuit protection.
Can I take the charger on a plane? Can I use it overseas?
1. Yes, it can be taken on a plane:
DJI Power 140W GaN Charger is a power adapter (containing no lithium batteries) and is not classified as a power bank. Therefore, it is generally not subject to air transport restrictions and can usually be carried in carry-on or checked luggage.
2. Supports global voltage:
It supports 100-240 V wide-range input, covering the power grid standards used in most countries and regions. With the appropriate adapter plug for the destination, it can be used during international travel.
DJI Power 140W GaN Charger is a power adapter (containing no lithium batteries) and is not classified as a power bank. Therefore, it is generally not subject to air transport restrictions and can usually be carried in carry-on or checked luggage.
2. Supports global voltage:
It supports 100-240 V wide-range input, covering the power grid standards used in most countries and regions. With the appropriate adapter plug for the destination, it can be used during international travel.
What do the different states of the DJI Logo LED indicator mean?
1. Solid on (low brightness): Powered on and on standby.
2. Solid on (high brightness): Charging a device.
3. Brief rapid blinking: A device has been connected or removed.
4. Continuous rapid blinking: Status exception.
5. Off: Sleep mode.
2. Solid on (high brightness): Charging a device.
3. Brief rapid blinking: A device has been connected or removed.
4. Continuous rapid blinking: Status exception.
5. Off: Sleep mode.
Do I need to connect the charger to an app during use?
No. DJI Power 140W GaN Charger is plug-and-play and does not require an app connection.
Why does the charging speed decrease after the charger has been used for a while?
DJI Power 140W GaN Charger features a built-in over-temperature protection system that monitors internal temperature in real time to reduce overheating risk. If the temperature gets too high, the charger automatically lowers output power until the temperature returns to normal. It is recommended to use the charger in a well-ventilated environment between 0° C (32° F) and 25° C (77° F) and to avoid covering or obstructing it to ensure optimal heat dissipation.
Why does a single port sometimes fail to reach 140W power output?
First, make sure the connected device supports 140W input, such as MacBook Pro 16-inch 2021 and later models.
Second, use a USB-C to USB-C cable that supports the EPR protocol (140 W or 240 W). DJI Power 7A USB-C Digital Display Cable is recommended.
In addition, charging power changes with the device's battery level. Once the battery level exceeds 80%, the device will typically reduce input power automatically to help protect battery health.
Second, use a USB-C to USB-C cable that supports the EPR protocol (140 W or 240 W). DJI Power 7A USB-C Digital Display Cable is recommended.
In addition, charging power changes with the device's battery level. Once the battery level exceeds 80%, the device will typically reduce input power automatically to help protect battery health.
Why doesn't the charger charge a phone as fast as its original charger?
Most mainstream phone fast-charging protocols typically support a maximum power range of 20 W to 34 W. Some phone brands use proprietary fast-charging protocols, which may limit charging power when a third-party charger is used. As a result, charging power may not reach the peak level of the original charger.
Which charging protocols does the charger support? What devices are compatible?
USB-C ports support PD 3.1, while USB-A port supports UFCS. All ports support QC 2.0/3.0, SCP, FCP, AFC, DCP, and Apple 2.4A protocols. Actual charging power depends on proprietary protocols or voltage/current limitations.
Check the Product Compatibility List for supported charging devices.
Check the Product Compatibility List for supported charging devices.
How is power allocated when multiple devices are charging simultaneously?
DJI Power 140W GaN Charger supports smart dynamic power allocation. When multiple ports are in use, it automatically adjusts the output of each port based on the number of connected devices and the port combination, such as USB-C1+USB-C2 or USB-C1+USB-A, to maintain charging efficiency. If a DJI device is connected to the USB-C1 or USB-C2 port, power output to that port is prioritized*, while the remaining power is dynamically allocated to the other ports. For specific power allocation details, please see the user manual or specifications page.
* If multiple ports are in use and one is connected to a DJI device, the charger supports dynamic power allocation and prioritizes power supply to connected DJI devices. This priority function is only available for select DJI devices and requires a DJI Power 7A USB-C Digital Display Cable connected to the USB-C1 or USB-C2 port. Unplug any idle cables when not in use to avoid limiting the max charging power of other ports.
* If multiple ports are in use and one is connected to a DJI device, the charger supports dynamic power allocation and prioritizes power supply to connected DJI devices. This priority function is only available for select DJI devices and requires a DJI Power 7A USB-C Digital Display Cable connected to the USB-C1 or USB-C2 port. Unplug any idle cables when not in use to avoid limiting the max charging power of other ports.
Will charging for the first device pause briefly when a second device is connected?
Equipped with dynamic power allocation technology*, DJI Power 140W GaN Charger allows existing devices to remain connected in most usage scenarios when a new device is plugged in. For devices supporting dynamic voltage protocols (e.g., PPS), a brief disconnection may occur as the charger re-initiates a protocol handshake to ensure safety and precise power allocation.
* If multiple ports are in use and one is connected to a DJI device, the charger supports dynamic power allocation and prioritizes power supply to connected DJI devices. This priority function is only available for select DJI devices and requires a DJI Power 7A USB-C Digital Display Cable connected to the USB-C1 or USB-C2 port. Unplug any idle cables when not in use to avoid limiting the max charging power of other ports.
* If multiple ports are in use and one is connected to a DJI device, the charger supports dynamic power allocation and prioritizes power supply to connected DJI devices. This priority function is only available for select DJI devices and requires a DJI Power 7A USB-C Digital Display Cable connected to the USB-C1 or USB-C2 port. Unplug any idle cables when not in use to avoid limiting the max charging power of other ports.
How do I use the priority charging function for DJI devices? Which DJI devices are supported?
When connected to the USB-C1 or USB-C2 port using the DJI Power 7A USB-C Digital Display Cable, the charger prioritizes power supply to the following DJI devices:
DJI Mavic 4 Pro Aircraft
DJI Mavic 4 Pro Battery Charging Hub
DJI Air 3 Aircraft
DJI Mini 5 Pro Two-Way Charging Hub
Osmo Pocket 4
Osmo Pocket 3
Osmo Multifunctional Battery Case 3.
DJI Mavic 4 Pro Aircraft
DJI Mavic 4 Pro Battery Charging Hub
DJI Air 3 Aircraft
DJI Mini 5 Pro Two-Way Charging Hub
Osmo Pocket 4
Osmo Pocket 3
Osmo Multifunctional Battery Case 3.
Digital Display Cable
Why do the values shown on the digital display cable differ from those shown on the charger or other third-party testing tools such as POWER-Z?
Differences in the readings are normal.
The main reasons are:
1. Display latency: Different devices use different sampling frequencies and screen refresh mechanisms, so the displayed real-time power may show slight timing differences.
2. Different sampling points: Each device reads voltage and current data at a different point in the circuit. Loss caused by line resistance can also create differences in the readings.
The main reasons are:
1. Display latency: Different devices use different sampling frequencies and screen refresh mechanisms, so the displayed real-time power may show slight timing differences.
2. Different sampling points: Each device reads voltage and current data at a different point in the circuit. Loss caused by line resistance can also create differences in the readings.
