Specs
Aircraft
Weight
26 kg (spraying without battery)
33 kg (spraying with battery)
Max Takeoff Weight[1]
Max takeoff weight for spraying: 53 kg
Max takeoff weight for spreading: 60 kg
Max Diagonal Wheelbase
1970 mm
Dimensions
Spraying:
2650×2700×820 mm (arms and propellers unfolded)
1520×1580×820 mm (arms unfolded and propellers folded)
1120×700×850 mm (arms and propellers folded)
Spreading:
2650×2700×850 mm (arms and propellers unfolded)
1520×1580×850 mm(arms unfolded and propellers folded)
1120×700×850 mm(arms and propellers folded)
Hovering Accuracy Range (with strong GNSS signal)
RTK enabled:
Horizontal: ±10 cm, Vertical: ±10 cm
RTK disabled:
Horizontal: ±60 cm, Vertical: ±30 cm
Max Configurable Flight Radius
2000 m
Operating Temperature
0° to 40° C
Max Wind Resistance
Level 3 wind (<6 m/s)
Propulsion System - Motors
Stator Size
100×28 mm
KV
59 RPM/V
Propulsion System - Propellers
Material
Nylon carbon fiber
Dimensions
50 in
Quantity
4
Spraying System - Spray Tank
Material
Plastic (HDPE)
Volume
20 L
Operating Payload
20 kg
Spraying System - Sprinklers
Model
LX07550SX
Quantity
Standard Configuration 2
Nozzle Distance
1420 mm (Rear Nozzles)
Droplet Size
50-500 μm
Effective Spray Width[2]
4-7 m (at a height of 3 m above the crops)
Spraying system - Delivery Pumps
Type
Impeller Pump (Magnetic Drive)
Quantity
2
Max Flow Rate
16 L/min (2 nozzles)
24 L/min (4 nozzles)
Spreading System 4.0
Compatible Material Diameter
0.5-5 mm dry granules
Spreading Tank Volume
30 L
Spreader structure type
Centrifugal Disc
Discharge Structure Type
Feeder Feeding
Max Discharge Rate
190 kg/min (compound fertilizer)
Max load inside the spreading operation box
25 kg
Effective spreading width[3]
3-8 m
Safety System 3.0
Millimeter-Wave Radar EIRP
<20 dBm (NCC/MIC/KC/CE/FCC)
Operating Temperature
0° to 40° C;
Operating Environment
Adequate light and discernible surroundings
Operating Frequency
24.05-24.25 GHz (NCC/FCC/MIC/KC/CE)
Field of View (FOV)
Front phased array digital radar: Horizontal 360°, Vertical ±45°, Upper ±45° (cone)
Rear phased array digital radar: Vertical 360°, Horizontal ±45°
Tri-camera vision system: Horizontal 90°, Vertical 180°
Range[4]
≤ 60 m
Effective safe obstacle avoidance speed[5]
≤ 10 m/s
Effective Obstacle Avoidance Height
≥ 1.5 m
Safe Distance
2.5m (Distance between the drone and obstacle after braking and stable hovering)
Remote Controller
Model
TKPL 2
Screen
7-inch LCD touchscreen; resolution: 1920×1200; brightness: 1400 cd/m²
Storage Temperature Range
Less than one month: -30° to 45° C (-22° to 113° F)
One to three months: -30° to 35° C (-22° to 95° F)
Three months to one year: -30° to 30° C (-22° to 86° F)
Charging Temperature
5° to 40° C (41° to 104° F)
Internal Battery Runtime
3.8 hours
External Battery Runtime
3.2 hours
Charging Type
It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable Charger.
Charging Time
2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger)
DB800 Intelligent Flight Battery
Weight
Approx. 6.6 kg
Capacity
15500 mAh
Nominal Voltage
52.22 V
D6000i Multifunctional Inverter Generator
Battery charging time[6]
To fully charge one battery (DB800 battery) takes 9-12 mins
Fuel tank capacity
20 L
Starting Method
Starting the Generator via the One-Button Start Switch
Max Power of Engine
6 kW
Fuel type
Unleaded gasoline with RON ≥91 (AKI ≥87) and alcohol content less than 10%
(*Brazil: unleaded gasoline with RON ≥ 91 and alcohol content of 27%)
Reference fuel consumption
600 ml/kWh
Engine Oil Capacity
0.8 L
Engine Oil Model
SJ10W-40
C8000 Intelligent Power Supply
Dimensions
300×280×230 mm
Weight
11.5 kg
Input
100-240 Vac
Output
Output Voltage: 59.92VOutput Current: 100A max
Charging Time[6]
Fully charges a battery in 9 to 12 minutes (DB800 Intelligent Flight Battery)
Protection Functions
Over-voltage, over-charge, under-voltage and over-temperature protection.
Charging Safety
AC wire protection, power wire protection, and charge connector protection
Annotation
[1] When the sea level height is measured, the DJI Agriculture App will intelligently recommend the load weight based on the current aircraft status, environmental conditions, and operational tasks. The maximum weight of the materials loaded by the user should not exceed the recommended value, as this may affect flight safety.
[2] The effective spray width of the spraying system depends on the actual working scene.
[3] The effective spreading width is measured at a flight altitude of 3 m, and the actual operation is related to the disc rotation speed, material type, material mu usage, and site environment.
[4] The observation distance of the safety system 3.0 varies due to different environmental light, rain, Fog, and the material, Location, and shape of the subject object.
[5] Except for linear obstacle scenes, damage to the aircraft due to obstacle avoidance failure within 10 m/s can be analyzed through log responsibility analysis, and non-human causes can be repaired for free; if there are wires, guy wires on Power Poles, and other linear obstacles, please mark them as obstacles, otherwise, failure to bypass obstacles will be the customer's responsibility.
Note:1. The downward perception is used to assist terrain-following altitude flight. If a collision with an obstacle occurs below, it is considered the customer's responsibility.2. Due to the performance limitations of the safety system, the aircraft cannot actively avoid moving objects. Accidents in such scenes are considered the customer's responsibility.
[6] Sea level height, environmental temperature between 15-40 degrees Celsius, time to charge the battery from 30% to 95%; fast charging is supported when the battery cell temperature is within the range of 15-75 degrees Celsius; charging time varies depending on input power, ASL, initial charge level, and other factors.
Footnotes
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Tutorial Videos
FAQ
Aircraft
What is the rotation direction of the propellers on the DJI Agras T25P?
What improvements have been made to the Power System of the DJI Agras T25P?
The heat dissipation performance has been improved, while also inheriting the T25P power system.
Spraying System
What is the atomization particle size of the DJI Agras T25P?
50-500 µm.
What are the advantages of single-side spraying with the DJI Agras T25P?
Activating the single-side spraying function can improve spraying effects around field boundaries and obstacles.
1. When the aircraft turns or makes a corner at the field boundary, the nozzle on the side close to the field boundary will be activated for spraying;
2. When the aircraft navigates around obstacles, the nozzle on the side close to the obstacle will be activated for spraying.
1. When the aircraft turns or makes a corner at the field boundary, the nozzle on the side close to the field boundary will be activated for spraying;
2. When the aircraft navigates around obstacles, the nozzle on the side close to the obstacle will be activated for spraying.
Does the DJI Agras T25P support operations without turning around when equipped with four nozzles? What functions are supported by the millimeter-wave radar and tri-vision system on the DJI Agras T25P?
Supported.
Safety System 3.0
What functions are supported by the millimeter-wave radar and tri-vision system equipped on DJI Agras T25P?
1. Supports horizontal omnidirectional obstacle avoidance and intelligent bypass in the direction of the aircraft's nose.
2. Supports large slope terrain-following operations.
2. Supports large slope terrain-following operations.
What are the precautions when using DJI Agras T25P Safety System 3.0?
1. Observation distance may vary due to environmental light, rain, fog, and the material, position, and shape of the target object.
2. When the vision is dirty or during nighttime operations, the aircraft will use pure radar for terrain-following bypass operations. The effectiveness of terrain-following bypass is reduced, so please fly cautiously.
2. When the vision is dirty or during nighttime operations, the aircraft will use pure radar for terrain-following bypass operations. The effectiveness of terrain-following bypass is reduced, so please fly cautiously.
What types of terrain is the terrain-following function without aerial survey of DJI Agras T25P suitable for?
Suitable for scenarios with many obstacles such as no power lines, diagonal cable, or dead trees.
Orchard Mode 4.0
Does the aerial survey mapping of DJI Agras T25P support Orchard Mode?
Yes, but to ensure the success rate of aerial survey mapping, T25P will automatically adjust the flight speed according to the slope of the mountain. The steeper the slope, the slower the speed, resulting in differences in aerial survey efficiency.
What features does Orchard Mode 4.0 have?
Supports 3D flight path spreading for orchards, row planning, and 3D flight path waypoint editing (waypoint height editing, waypoint position adjustment, adding and deleting waypoints).
Can DJI Agras T25P operate on orchards?
Yes.
Smart flight battery and recharge equipment
Does DJI Agras T25P come standard with an air-cooled radiator?
Not a standard accessory.
Which multifunctional inverter generator is included in the T25P flagship package?
The Agras T25P flagship package includes the D6000i Multifunctional Inverter Generator.
Spreading system
How many feeders are included in the standard configuration of the DJI Agras T25P spreading system? What type of materials is it suitable for?
Includes 3 feeders, suitable for materials with a particle size range of 0.5-10 mm.
How is the compatibility of the DJI Agras T25P spreading system?
It is not compatible with the spreaders and tanks of DJI Agras T70P/T100.
What is the function of the annular baffle on the spreading disc of the DJI Agras T25P Spreading System accessories?
The annular baffle installed on the spreading disc can be used to improve the uniformity of spreading under low flow conditions. It must be used with a small feeder.
How to choose the appropriate feeder for the DJI Agras T25P Spreading System?
Choose the appropriate feeder based on the per-acre usage, particle type, and size of the material being spread.
Can the DJI Agras T25P Spreading System discharge normally after removing the spreading disc?
It can be used normally after removing the spinning disc, suitable for scenarios like aquaculture and fertilizing lotus fields.
Smart Remote Controller & Video Transmission
Is the RTK high-precision positioning module of the DJI Agras T25P Smart Remote Controller a standard feature?
Not a standard accessory.
Is the external battery of the DJI Agras T25P Smart Remote Controller standard or optional?
Optional accessory.
Does the DJI Agras T25P Smart Remote Controller support T100/T70P/T25P?
No, it is not compatible.
Remote Controller
What upgrades does the remote controller of the DJI Agras T25 have compared to the DJI T25P Agricultural Drone?
The all-new DJI RC PLUS 2 remote controller offers stronger performance, higher screen brightness, longer range with internal and external batteries, added button backlight for easier nighttime operation, and a wealth of custom physical buttons for flexible handling.
